6″ Locking Slide Arm with Short Clevis – 7160-1160 | 7160-1160

Description

6″ Locking Slide Arm with Short Clevis Gamber-Johnson part number 7160-1160.SpecificationsWeightWeight: 5.2 lbs. (3.08 kg)HeightHeight: 3.9″ (9.9 cm)WidthWidth: 7.2″ (18.4 cm)DepthLength: 9.4″ (23.9 cm)FeaturesEntire motion attachment capable of rotating 360 degree with locking every 15 degrees Tilt capabilities: 45 forward Swivel capabilities: 360 The entire arm can rotate around 360 with locking points at every 15 Slide motion is up to 5.5 inches (13.97 cm) fore/aft To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever Heavy duty, spring loaded steel, side pin was tested to 50,000+ cycles Can be mounted directly to a flat surface or on any Upper Pole, Center Pole, Low Profile Bracket, GJ console box via Smiley Face or 3-Bolt Hole pattern Heavy gauge steel construction for long-term durability Black powdercoat finish for maximumProduct DetailsWarranty: Limited Lifetime WarrantySpecification: Mounting plate hole patterns: AMPS (4 hole rectangle shaped) – 3 locations, one turned 90 degrees, NEC (3 hole triangle shaped), VESA 75mm, Gamber-Johnson 2x4Industry: Fire/Rescue, Intermodal, Logistics, Material Handling, Public Safety, UtilitySub Type 1: Motion AttachmentSub Type 2: Locking Slide ArmSub Type 3: With ClevisDownloadsInstallation Guide (PDF)
