Description

General Specifications
Compatibility Intel Socket: 1851, 1700, 1200, 115X, 2011-3*, 2066* (*Square ILM)
AMD Socket: AM5, AM4
RAM Clearance Unlimited
Operating Ambient Temperature 040 C
Pump / Cold Plate
VRM Fan 40 mm, 10003000 rpm (PWM controlled)
Pump Speed 8002000 rpm (PWM controlled)
Power Consumption 0.5 W2.7 W (Pump + VRM Fan)
Cold Plate Copper, Micro-Skived-Fins
Thermal Paste MX-4 (0.8 g)
Fan
Fan Model ARCTIC P14 140 mm Fan x2
Fan Speed 2001700 rpm (PWM controlled)
0 rpm below 5% PWM
Fan Bearing Fluid Dynamic Bearing
Noise Level 0.3 Sone
Current | Voltage 0.12 A | 12 V DC
Airflow 72.84 cfm | 123.76 m/h
Static Pressure 2.4 mmH2O
Connector 4-Pin Connector
Size & Weight
Radiator Dimensions 317 (L) x 138 (W) x 38 (H) mm
Pump Dimensions (without tubes) 78 (L) x 53 (W) x 98 (H) mm
Tube Diameter Outer: 12.4 mm | Inner: 6.0 mm
Tube Length 450 mm
Weight 1572 g (Fan, Radiator, Pump, Tubes)
Packaging
Packaging Dimensions (W x H x L) 156 x 172 x 336 mm
Packaging Weight 2.1 kg
