The right way up

• The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation

• Low-permeability rubber tubes with braided nylon sleeves

From subtle to stunning

• Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI

• Six ARGB LEDs are yours to command via your motherboard or controller

Forget the thermal paste

• Thermal paste is pre-applied to ensure a proper and pain-free installation

• Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing

Common denominators

• Compatible with LGA 1700 and AM5

• Supports the most common sockets for both Intel and AMD

General specifications

• Sockets supported (Intel)LGA 1700*/ 1851*/1150/1151/1155/1156/1200 LGA 1366/2011/2011-3/2066
• Sockets supported (AMD)AM5 / AM4/FM2+/FM2/ FM1/AM3+/AM3/AM2+/AM2
• * Compatible using updated LGA 1700 bracket, contact Fractal support to request one if using an older version
• Cold plate materialCopper
• Thermal pastePre-applied
• Tube length400mm
• Tube materialLow-permeability rubber with braided nylon sleeve
• Fittings, block sideArticulating 90-degree Elbow
• Fittings, radiator sideBarbed fitting
• Block height43mm
• Block measurements (with fittings)79 x 67 mm
• Block diameter (main block body)67 mm

Fan specifications

• Fan typeAspect 12 RGB PWM
• Rotational speed5002000 RPM
• Fan bearingRifle bearings
• Fan PWM controlYes
• Fan acoustical noise<1033.2 dBA
• Fan maximum air flow13-56 CFM
• Fan maximum static pressure0.2302.34 mm H2O
• Fan input voltage12V
• Fan maximum input current0.37A
• Fan MTTF90,000 hours

Pump specifications

• Rotational speed4000 10% RPM
• Bearing typeCeramic
• PWM controlNo
• Acoustical noise (full speed)22 dBA
• Maximum pressure1.8 mm H2O/ 17.6 kPa / 2.5 PSI
• Input voltage12V DC
• Input current (without fans)0.34 A
• MTTF50 000 hours

Radiator specifications

• Radiator dimensions272 x 120 x 27 mm
• Radiator housing materialAluminum
• Radiator fin materialAluminum
• Radiator fan screw threads6-32

Other

• Package contentsCPU Cooler Assembly, 2x Aspect 12 RGB fans, User manual, Intel mounting kit, AMD mounting kit, 5V ARGB cable
• Package dimensions332 x 205 x 137 mm
• Package weight1.77kg
• Product CodeFD-W-L1-S2412
