Description

Chipset AMD B550
CPU Support AMD Ryzen 5000 & 3000 Series, Ryzen 4000 G-Series
Socket AM4
Memory Slots 4 DDR4 UDIMM
Maximum Memory 128GB
Memory Speed Up to DDR4-4866+ MHz (OC)
Memory Architecture Dual Channel
PCIe x16 Slots 2 PCIe x16
PCIe x1 Slot 1 PCIe x1
Primary PCIe PCIe 4.0 x16
M.2 Slots 2 M.2
M.2 Support 1 PCIe 4.0 x4 / SATA, 1 PCIe 3.0 x4
SATA 6 SATA 6Gb/s
LAN Realtek 8111H 1Gbps LAN
Audio Realtek ALC897, 7.1-Channel HD Audio
Video Outputs HDMI 1.4, DisplayPort 1.2
USB USB 2.0, USB 5Gbps, USB 10Gbps Type-A & Type-C
RGB 2 Addressable RGB V2 + 1 RGB
Debug Feature 4 EZ Debug LED
BIOS Feature Flash BIOS Button
Operating System Windows 11 64-bit
Form Factor ATX
Dimensions 243.84 304.8 mm
