Description

CPU AMD
Socket Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Back Panel I/O HDMI
VGA
Keyboard/Mouse
USB 3.2 Gen 1 5Gbps (Type-A)
LAN port
Audio connectors
USB 2.0
Memory Slots 2x DDR5, Maximum Memory Capacity 128GB
Storage Expansion 1x M.2
4x SATA 6G
Internal I/O 1x Power Connector(ATX_PWR)
1x Power Connector(ATX_PWR)
1x CPU Fan
2x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
Audio Realtek ALC897 Codec
7.1-Channel High Definition Audio
Supports up to 32-Bit/384 kHz playback on front panel
Software Support for Windows 11 64-bit, Windows 10 64-bit
Dimensions mATX
211mmx243.84mm
