Description

Motherboard Support E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
Enclosure Type Mid-Tower
Case Material SGCC Steel, Ultra-Clear Tempered Glass (White)

Dimensions

544 x 244 x544mm
Weight 11.13 kg
CPU Cooler Clearance Up to 185mm
GPU Clearance Up to 410 mm
PSU Clearance Up to 200 mm
Cable Management Up to 34.5 mm
USB 3.2 Gen 1 Type-A 2
USB 3.2 Gen 2×2 Type-C (20 Gbps) 1
Headset Audio Jack 1

Expension Slots

7

Drive Bays

2.5″:2+2
3.5″:2

Fan Support

Front:3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included)

Top:3 x 120 mm / 2 x 140 mm

Bottom:3 x 120 mm

Rear:1 x 120 mm / 1 x 140 mm

Filters:High-Performance Mesh

Radiator Support

Front:Up to 420 mm

Top:Up to 360mm

Rear:Up to 140mm

Fan Specs

Model:F360 RGB Core Fan (Case Version)

Speed:1,700 200 RPM

Airflow:50.1 CFM

Static:1.27 mm-HO

Noise:23.3 dBA

Fan Connector:3-pin
