18.5″ Full HD Rugged Waterproof Industrial HDMI Touch Monitor

Description

Description Show Reviews Key Featured 18.5, Industrial Grade TFT LCD Panel, Standard HDMI Input 1920 x 1080 Full HD Resolution USB multi-touch capacitive touch screen 290 nits of brightness, support adjustable controls IP65 rated dustproof & waterproof for the front panel Embedded & VESA mounting ED-MONITOR-185C is an 18.5 industrial HDMI touch monitor. The flat front panel is slim and compact, with IP65 grade dustproof and waterproof process, it is the preferred model for embedded installation of cabinet equipment. With a resolution of up to 1920 x 1080, it supports USB multi-touch, is drive-free and ready to use, and has a built-in audio output interface, which is perfectly adapted to Raspberry Pi and other platforms. Aluminum alloy screen frame and sheet metal shell mechanical design, enhance the mechanical rigidity of the machine, anti-interference and heat dissipation performance.It is fearless of high and low temperatures, oil, dust, vibration and other harsh working conditions, is the ideal choice for industrial control, terminal support, human-computer interaction. Specification Panel I/O HDMI 1 x HDMI port, Type-A connector, connecting to HDMI output. USB 1 x USB touch screen interface (Type-C USB) for connecting to USB interface and transmitting touch screen signals. Audio 1 x 3.5mm audio jack, stereo audio output Power 1 x DC Jack port, support 12V~24V power input. Buttons and Indicators PWR 1 x Red power indicator, using to check the status of device power-on and power-off. Brightness Adjustment Button 2 x Brightness adjustment buttons for increasing and decreasing the brightness. Volume Adjustment Button 2 x Volume adjustment buttons for increasing and decreasing the volume. Mute Button 1 x Mute button for mute and unmute audio. LCD Type 18.5″ TFT Resolution 1920 x 1080 Color Number 16.7M Active Area 408.96mm (H) x 230.04mm (V) Backlight LED Luminance 290cd/m 2 Contrast Ratio 1000:1 Response Time 14ms Viewing Angle (CR10) 80 (L) / 80 (R) / 80 (U) / 80 (D) Touch Screen Type Capacitive Touch Screen multi-touch Up to 5 points Communication Method USB Transmittance 85 Surface Hardness 6H Electrical Characteristics Input Voltage 12V~24V DC Power Consumption 15W (Max) Mechanical Characteristics Dimensions 457.3mm x 278.3mm x 35mm (WxDxH) Weight About 3.1kg Installation Embedded front installation and VESA bracket mounting Environmental & Regulatory Operating Temperature -10C ~ 60C Storage Temperature -20C ~ 70C Ambient humidity 5% ~ 95% (non-condensing) Mechanicals Docs ED-MONITOR-185C Datasheet 0 Reviews Hide Reviews Show Reviews
